September 26, 2021 - Fuse No.Fuse NameAmpsComponent or Circuit Protected1--Not Used2--Not Used3(RR WIPER RR WASHER)10ARear Wiper, Security System (Option)(Vehicles Pre-Wired for Accessory Security System)4R H/L HIGH BEAM10ARight Headlight, DRL Control Unit (Canada)5L H/L HIGH BEAM10ALfet Headlight, DRL Control ... In this article, we consider the sixth-generation Honda Civic, produced from 1996 to 2000. Here you will find fuse box diagrams of Honda Civic 1996, 1997, 1998, 1999 and 2000, get information about the location of the fuse panels inside the car, and learn about the assignment of each fuse (fuse ...
